FEATURES
• Supports NVIDIA® Jetson Orin Nano™ with Super Mode and Jetson Orin™ NX
• 1 x M.2 B-Key/ E-Key/ M-Key (NVMe 128GB built-in)
• 1 x RJ-45 for GbE
• 2 x IEEE 802.3af GbE PSE Ports
• Power Input Voltage Range 12 to 24 VDC
• Operating temperature -25°C ~ +55°C
Specifications
| Specification | AIE-CO23-S1 | AIE-CO33-S1 | AIE-CN33-A1 | AIE-CN43-A1 |
| AI Performance | 34 TOPS | 67 TOPS | 70 TOPS | 100 TOPS |
| Module Compatibility | NVIDIA Jetson Orin Nano Super 4GB | NVIDIA Jetson Orin Nano Super 8GB | NVIDIA Jetson Orin NX 8GB | NVIDIA Jetson Orin NX 16GB |
| GPU | 512 CUDA Cores, 16 Tensor Cores | 1024 CUDA Cores, 32 Tensor Cores | 1024 CUDA Cores, 32 Tensor Cores | 1024 CUDA Cores, 32 Tensor Cores |
| CPU | 6-Core Arm Cortex-A78AE, 64-bit, 1.5MB L2 + 4MB L3 | 6-Core Arm Cortex-A78AE, 64-bit, 2MB L2 + 4MB L3 | 6-Core Arm Cortex-A78AE, 64-bit, 2MB L2 + 4MB L3 | 8-Core Arm Cortex-A78AE, 64-bit, 2MB L2 + 4MB L3 |
| Memory | 4GB LPDDR5, 64-bit, 51 GB/s | 8GB LPDDR5, 128-bit, 68 GB/s | 8GB LPDDR5, 128-bit, 102.4 GB/s | 16GB LPDDR5, 128-bit, 102.4 GB/s |
| Storage | 1 x M.2 M-Key 2242 (NVMe 128GB built-in) | |
| Display | 1 x HDMI 2.0 Type A | |
| TPM | TPM | |
| RTC | RTC Battery | |
| LAN | 2 x RJ-45 GbE ports | |
| PoE Interface | 2 x RJ-45 GbE PSE (IEEE 802.3af compliant, Power Output 15W/Port, Total PSE ports support up to 30W ) | |
| I/O Interfaces | 2 x USB 3.2 Gen2 Type A (supports up to 10Gbps shared) 1 x USB 2.0 Gen2 Type A 1 x OTG Type-C |
|
| Expansion | 1 x M.2 B-Key 3052 (LTE) 1 x M.2 E-Key 2230 (WiFi/BT) 1 x M.2 M-Key 2242 (NVMe 128GB built-in) 4 x GPIO, 1 x SPI, 2 x I2C, 1 x UART 1 x CAN (Isolation; support CAN FD), 1 x RS-422/485/232 (switch 3-in1) |
|
| MISC. Function | 1 x Recovery / 1 x Reset Button | |
| Power Consumption | Idle: TBD W Full Loading: TBD* W |
Idle: TBD W Full Loading: TBD* W |
| *For more test condition information, please refer to user manual | ||
| Power Input/Connector | DC-in 12 to 24 VDC / 2-Pin Terminal Block | |
| Dimension (WxDxH) | 132 x 91.5 x 68.5 mm | |
| Net Weight | TBD kg (TBD lb) | |
| Vibration | 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |
| Shock | 10 G, IEC 60068-2-27, half sine, 11 ms duration | |
| Temperature | Operating Temp.: -25°C ~ +55°C (-13°F ~ +131°F) Storage Temp.: -40°C ~ +85°C (-40°F ~ +185°F) |
|
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |
| Software Support | Linux (Support NVIDIA Jetpack 6.2 and above) | |
| Certification | CE / FCC Class A / UKCA | |
