Specifications

Specification	Details
Cellular Technology	4G LTE Cat 1 bis
Max LTE Speed	10 Mbps Download / 5 Mbps Upload
SIM Slots	2 × Mini-SIM (2FF) with auto-failover
Ethernet Port	1 × RJ45 (10/100 Mbps)
Serial Interfaces	1 × RS232, 1 × RS485
Digital I/O	3 × configurable Digital Inputs / Outputs
GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS
Antenna Connectors	1 × SMA (LTE), 1 × SMA (GNSS)
CPU	MIPS 24KEc 580 MHz
RAM	128 MB DDR2
Flash Storage	16 MB SPI flash
Operating System	RutOS (Linux/OpenWRT based)
Industrial Protocols	Modbus, DNP3, DLMS/COSEM, OPC UA, BACnet, MQTT
Power Input	9 – 30 V DC (via 16-pin terminal block)
Housing	Industrial Aluminum
Protection Rating	IP30
Operating Temperature	−40 °C to +75 °C
Dimensions	83 × 25 × 82.6 mm
Mounting	DIN Rail / Wall mount
