Product Availability : Against PO
Country Of Origin: Taiwan
FEATURES
- 4G LTE Cat 6 Connectivity – Supports cellular speeds up to 300 Mbps download using carrier aggregation.
- Gigabit Ethernet Port – 1 × RJ45 (10/100/1000 Mbps) for high-speed wired connection.
- USB Type-C Interface – Used for power supply and data communication through a single cable.
- Industrial Protocol Support – Supports OPC UA, Modbus, MQTT, DNP3, DLMS, Data-to-Server and other IoT protocols.
- Compact Industrial Design – Small, lightweight gateway for easy installation in industrial cabinets.
- Remote Management Support – Compatible with Teltonika RMS (Remote Management System) for remote monitoring and configuration.
- Digital I/O Interface – 1 digital input and 1 digital output for automation devices and sensors.
- Wide Temperature Range – Operates from −40 °C to +75 °C for industrial environments.
DOWNLOAD
trb160-datasheet-v12
Specifications
| Specification | Details |
|---|---|
| Cellular Connectivity | 4G LTE Cat 6, 3G |
| Max LTE Speed | Up to 300 Mbps download / 50 Mbps upload |
| Ethernet Port | 1 × RJ45 Gigabit (10/100/1000 Mbps) |
| SIM Slot | 1 × Mini-SIM (2FF) |
| Antenna Connectors | 2 × SMA (for LTE antennas) |
| USB Interface | 1 × USB Type-C (power + data) |
| Digital I/O | 1 × Digital Input, 1 × Digital Output |
| CPU | ARM Cortex-A7, 1.2 GHz |
| RAM | 128 MB |
| Flash Storage | 256 MB |
| Operating System | RutOS (Linux / OpenWRT based) |
| Power Input | 9 – 30 V DC |
| Power Consumption | Max ~3.3 W |
| Mounting Options | DIN Rail / Wall / Surface |
| Protection Rating | IP30 |
| Operating Temperature | −40°C to +75°C |
| Dimensions | 83 × 25 × 74.2 mm |
| Housing | Industrial Anodized Aluminum |
