Product Availability : Against PO
Country Of Origin: Taiwan
FEATURES
- 4G LTE Connectivity – Supports 4G LTE (Cat 4), 3G, and 2G networks for reliable remote communication.
- M-Bus Interface – Connects up to 250 M-Bus meter devices for utility monitoring (water, gas, electricity).
- Gigabit Ethernet Port – 1 × RJ45 (10/100/1000 Mbps) for LAN connectivity.
- Industrial Rugged Design – Aluminum housing designed for harsh industrial environments.
- Wide Operating Temperature – Works from −40°C to +75°C.
- Digital I/O Support – 2 configurable digital inputs/outputs for automation and monitoring.
- RutOS Operating System – Linux-based firmware supporting VPN, MQTT, Modbus, and IoT protocols.
- Remote Management (RMS) – Compatible with Teltonika Remote Management System for monitoring and control.
- SMS & Remote Control – Supports SMS commands, alerts, and remote configuration.
- Compact Industrial Gateway – Small size for DIN-rail, wall, or surface installation.
DOWNLOAD
trb143-datasheet-v1
Specifications
| Specification | Details |
|---|---|
| Device Type | Industrial LTE Gateway |
| Cellular Connectivity | 4G LTE (Cat 4), 3G, 2G |
| Max LTE Speed | Up to 150 Mbps download |
| Ethernet Port | 1 × RJ45 (10/100/1000 Mbps) |
| M-Bus Interface | Supports up to 250 slave devices |
| Digital I/O | 2 × configurable inputs/outputs |
| CPU | ARM Cortex-A7 1.2 GHz |
| RAM | 256 MB |
| Flash Storage | 512 MB |
| Operating System | RutOS (based on OpenWRT) |
| Network Protocols | TCP, UDP, IPv4, IPv6, DHCP, SNMP, MQTT, HTTP/HTTPS |
| VPN Support | OpenVPN, IPsec, WireGuard, GRE, PPTP, L2TP |
| Remote Management | RMS (Teltonika Remote Management System) |
| Power Input | 9 – 30 V DC |
| SIM Slot | 1 × Mini-SIM (2FF) |
| Housing | Industrial Aluminum |
| Protection Rating | IP30 |
| Operating Temperature | −40°C to +75°C |
| Dimensions | 74.5 × 25 × 73 mm |
| Weight | ~145 g |
