FEATURES
• Supports Super Mode for NVIDIA® Jetson Orin Nano™ /Orin™ NX
• 1 x M.2 B-Key/E-Key/M-Key (NVMe 128GB built-in)
• 2 x RJ-45 GbE Ports
• Wide Input Voltage Range 12 to 24 VDC
• Operating temperature -25°C ~ +55°C
• Fanless Design
Specifications
| Specifications | ||||
| Model Number | AIE-PO22-1-S2 | AIE-PO32-1-S2 | AIE-PN32-1-S2 | AIE-PN42-1-S2 |
| Module Compatibility | NVIDIA Jetson Orin Nano with Super Mode 4GB | NVIDIA Jetson Orin Nano with Super Mode 8GB | NVIDIA Jetson Orin NX with Super Mode 8GB | NVIDIA Jetson Orin NX with Super Mode 16GB |
| AI Performance | 34 TOPS | 67 TOPS | 117 TOPS | 157 TOPS |
| GPU | 512 Core NVIDIA Ampere, with 16 Tensor Cores | 1024 Core NVIDIA Ampere, with 32 Tensor Cores | 1024 Core NVIDIA Ampere, with 32 Tensor Cores | |
| CPU | 6-core Arm® Cortex®-A78AE v8.2 64-bit 1.5MB L2 + 4MB L3 | 6-core Arm® Cortex® -A78AE v8.2 64-bit 2MB L2 + 4MB L3 | 8-core Arm® Cortex® -A78AE v8.2 64-bit 2MB L2 + 4MB L3 | |
| Memory | 4GB 64-bit LPDDR5 51 GB/s | 8GB 128-bit LPDDR5 68 GB/s | 8GB 128-bit LPDDR5 102.4 GB/s | 16GB 128-bit LPDDR5 102.4 GB/s |
| Storage | 1 x M.2 M-Key 2242 (NVMe 128GB built-in) | |
| Display | 1 x HDMI 2.0 Type A | |
| RTC | RTC Battery 2032 | |
| LAN | 2 x RJ-45 GbE Ports | |
| USB | 2 x USB 3.2 Gen2 Type A (supports up to 10Gbps shared) 1 x OTG Type-C |
|
| I/O Interfaces | 5 x GPIO, 1 x UART, 1 x I2C, 1 x RS-232, 1 x RS-422/485 (2-in-1), 1 x CAN (isolation; support CAN FD) |
|
| Expansion | 1 x M.2 B-Key 3042/3052 (LTE/4G/5G) with 1PPS function supported at 1.8V / 3.3V) 1 x M.2 E-Key 2230 (WiFi/BT) 1 x M.2 M-Key 2242 (NVMe 128GB built-in) |
|
| MISC. Function | 1 x Power Button, 1 x Recovery Button, 1 x Reset Button | |
| Power Input/Connector | DC-in 12-24VDC / 4-Pin DC Jack Power Connector | |
| Power Consumption | Idle: 6.413 W Full Loading: 43.13* W |
Idle: 6.413 W Full Loading: 43.13* W |
| *For more test condition information, please refer to user manual | ||
| Dimension (WxDxH) | 270 x 195 x 80 mm (10.63 x 7.67 x 3.15 in) | |
| Mounting | Wall Mount (optional) / Din Rail (optional) | |
| Net Weight | 4.2 kg (9.7 lb) | |
| Vibration | 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |
| Shock | 10 G, IEC 60068-2-27, half sine, 11 ms duration | |
| Temperature | Operating Temp.: -25°C ~ +55°C (-13°F ~ +131°F) with 0.5 m/s air flow Storage Temp.: -40°C ~ +85°C (-40°F ~ +185°F) *With full CPU+GPU stressing: System non-throttling at 50C with 40W (MAXN Mode) |
|
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |
| Software Support | Linux (Support NVIDIA JetPack 6.2 and above) | |
| Certification | CE / FCC Class A / UKCA | |
