FEATURES
-
Dual SIM support → Uses two SIM cards for automatic failover (backup internet)
-
4G LTE connectivity → High-speed mobile internet
-
Wi-Fi → Can create a wireless network for devices
-
GNSS (GPS support) → Location tracking capability
-
Multiple Ethernet ports → Connect wired devices
-
Industrial design → Works in harsh environments (temperature, vibration, etc.)
DOWNLOAD
rut976-datasheet-v172
Specifications
| Category | Specification |
|---|---|
| Technology | 5G RedCap (SA), 4G LTE Cat 4 fallback |
| Speed | 5G: 223 Mbps DL / 123 Mbps UL4G: 195 Mbps DL / 105 Mbps UL |
| SIM | Dual SIM (2FF) + eSIM (optional) |
| Failover | Auto SIM switching (backup internet) |
| Wi-Fi | Yes (connect multiple devices) |
| Ethernet Ports | 4 × RJ45 (10/100 Mbps) |
| GNSS (GPS) | GPS, GLONASS, Galileo, BeiDou |
| Interfaces | RS232, RS485, Digital Inputs/Outputs |
| USB | 1 × USB 2.0 port |
| Storage | MicroSD (up to 2TB) |
| Processor | Mediatek 580 MHz |
| RAM / Flash | 128 MB RAM / 16 MB Flash |
| OS | RutOS (Linux / OpenWrt based) |
| VPN & Security | VPN, Firewall, SSL support |
| Remote Management | RMS (Teltonika Remote System) |
| Power Input | 9–30 V DC |
| Power Consumption | Idle < 3W, Max < 7W |
| Dimensions | 110 × 50 × 100 mm |
| Weight | 295 g |
| Mounting | DIN rail / Wall / Surface |
| Operating Temp | -40°C to +75°C |
| Protection | IP30 Industrial grade |
